برد آردوینو LilyPad دارای پردازنده مرکزی ATmega328

برد آردوینو LilyPad دارای پردازنده مرکزی ATmega328

55,500 تومان

در انبار موجود نمی باشد

شناسه محصول: 22121033 دسته: برچسب: ,

توضیحات محصول

Description:

The Arduino Compatible LilyPad is a microcontroller board designed for wearables and e-textiles. It can be sewn to fabric and similarly mounted power supplies, sensors and actuators with conductive thread. The board is based on the ATmega328 with the Arduino bootloader. The main board has a minimum number of external components to keep it as small (and as simple) as possible. The latest version supports automatic reset for even easier programming. The back side of the LilyPad is completely flat. It uses a surface mount programming connector, which keep the header from poking through.

Specification:

Microcontroller: ATmega328P
Operating voltage: 2.7V ~ 5.5V (recommended 5V)
Input voltage: 2.7V ~ 5.5V (recommended 5V)
Digital I/O pins: 14 (of which 6 provide PWM output)
Analog input pins: 6
DC current per I/O pin: 40mA
Flash memory: 16KB (of which 2KB used by bootloader)
SRAM: 1KB
EEPROM: 512bytes
Clock speed: 16MHz
